Level 1B File Naming
| Spacecraft | GEO-KOMPSAT-2B | Sensor | GOCI-II | |
|---|---|---|---|---|
| Processing Level |
Level 1B | |||
|
File naming * Underscores are separators in file name. * The order of texts may change. |
Example |
GK2_①GOCI2_②L1B_③
20220213_④021530_⑤LA_⑥
S000⑦.nc⑧
|
||
| Order | Name | Position of texts | Description |
|
| ① | Satellite Name | 1-3 | GK2 : Spacecraft is GEO-KOMPSAT-2B | |
| ② | Sensor | 5-9 | GOCI2 : Sensor name is GOCI-II | |
| ③ | Processing Level | 11-13 | L1B : Processing level is 1B | |
| ④ | Acquisition Date | 15-22 | Image acquisition date | |
| ⑤ | Acquisition Time | 24-29 | Image acquisition time (UTC) | |
| ⑥ | Coverage | 31-32 | LA : Local Area / FD : Full Disk | |
| ⑦ | Slot number | 34-37 |
S### : ### is from 000 to 011. * If slot numbers do not exist, it indicates an image with all slots merged. |
|
| ⑧ | File format | 39-41 | NC : NetCDF Tif : GeoTIFF JPG : JPEG(for thumbnail) |
|
